| Model |
Voltaj (v) |
Güç (kw) |
Frekans (hz) |
Devir (rpm) |
Debi (m³/h) |
|---|---|---|---|---|---|
| AVS-IGK250 | 230 | 2 X 200 | 48 | 2800 | 750 |
| AVS-IGK280 | 230 | 2 X 250 | 56 | 2800 | 1000 |
| AVS-IGK315 | 230 | 2 X 140 | 66 | 1400 | 1500 |
| AVS-IGK355 | 230 | 2 X 220 | 68 | 1400 | 2000 |
| AVS-IGK400 | 230 | 2 X 560 | 74 | 1400 | 3000 |
| AVS-IGK450 | 230 | 2 X 750 | 78 | 1400 | 4000 |
| AVS-IGK500 | 230 | 2 X 1250 | 86 | 1400 | 5000 |
| Model | A (mm) | B (mm) | C1 (mm) | D (mm) | E (mm) |
|---|---|---|---|---|---|
| AVS-IGK250 | 940mm | 360mm | 1140mm | 210mm | 230mm |
| AVS-IGK280 | 940mm | 360mm | 1140mm | 210mm | 260mm |
| AVS-IGK315 | 940mm | 420mm | 1350mm | 300mm | 320mm |
| AVS-IGK355 | 1000mm | 450mm | 1550mm | 360mm | 400mm |
| AVS-IGK400 | 1150mm | 500mm | 1750mm | 360mm | 400mm |
| AVS-IGK450 | 1150mm | 575mm | 1750mm | 360mm | 400mm |
| AVS-IGK500 | 1250mm | 620mm | 1950mm | 360mm | 400mm |
